Plastic Centrifugal Water Pump

Model:CN142P

One of Chinese manufacturer of Plastic Centrifugal Water Pump, offering excellent quality at a competitive price, is SMZ®. Feel free to get in touch.

Send Inquiry

Product Description

Another great feature of this pump is its durability. Made from sturdy plastic materials, it is built to last even under extreme conditions. In addition, it is resistant to corrosion and other types of wear and tear, which means that it can withstand exposure to a wide range of substances and environmental factors. The Plastic Centrifugal Water Pump is easy to install and maintain. Its compact size and lightweight make it simple to move around and install in tight spaces where other pumps cannot fit. Additionally, its self-priming feature ensures that the pump is ready to use in a matter of seconds, saving you precious time and effort.

In terms of performance, this pump is capable of handling a wide variety of liquids, including water, chemicals, and other substances. It is also capable of achieving high head heights and can maintain a steady flow rate even under heavy use. The pump is crafted using premium quality plastic that makes it corrosion-resistant and perfect for pumping hazardous substances. Thanks to its centrifugal design, it is able to deliver high flow rates with low power consumption, lowering your operational costs while ensuring optimal performance.

One of the key benefits of our Plastic Centrifugal Water Pump is its ability to pump not only water but also other types of liquids such as acids, alkalis, and oils. This makes it an excellent choice for a variety of industries including chemical processing plants, industrial facilities, and manufacturing plants.

The following is an introduction of CNP Series .It is plastic centrifugal water pump which is widely used in the food & medical industry and sea water purity industry ..Hope to help you better understand Risefull Indutrial water pump . Welcome new and old customers to continue to cooperate with us to create a better future together

Product Specification:

Product Name:	Plastic centrifugal water pump
Power	0.65HP
Max Flow	90L/min
Max Head	25M
Inlet/outlet	1”X1”
Pump Body	Plastic
Bracket	Cast Iron
Bracket Plate	Plastic
Shaft	S.S Shaft
Impeller	PPO Impeller
Motor	Copper wire
Color	Powder Color Coating
MOQ:	100pcs
Sample Time:	Within 7 days
Production Time:	35-40 days after order confirmation
Certificate	CE

Product Details

Working Condition

● Clean liquid without suspend solids ,non aggressive

● Continuous Service :S1

● Maximum Pressure:10 Bar

● Liquid Temperature:0℃~90℃

● Ambient Temperature:<40℃

● Insulation:B

● Protection:IP44

Performance Data

Plastic Centrifugal Water Pump

Model		Power		Q	m³/h	0	0.6	1.2	1.8	2.4	3.0	3.6	4.2	4.8	5.4
Single-phase	Three-phase	kW	HP	Q	L/min	0	10	20	30	40	50	60	70	80	90
CN142XP	CN142XPT	0.5	0.65	H	M	27	26.5	26	25.5	24.5	*24	*23.5	*21.5	*20	15

*High Efficiency Eta Of Pump

Plastic Centrifugal Water Pump

List of Main Component ●Standard Configuration 〇 Optional Configuration
NO.	Component	Specification/Construction Characteristics
1	PUMP BODY	Plastic
2	IMPELLER	PO（High Temperature Resistant for 150℃）
3	Mechanical Seal	14DIN Type（Furan Impregnation Graphite+SIC，Use Life 25,000+ Hours）
4	Bracket Plate	PPO（High Temperature Resistant For 150℃）
5	Bracket	Cast Iron HT200
6	Ball Bearings	〇Standard Type ● C&U 〇 TPI(Taiwan)
7	Motor Shaft	Welding Shaft: Stainless Steel 304 (Pump Side)+Carbon Steel (Motor Side)
8	Terminal Box	Plastic ABS
9	Terminal Board	Flame Retarding PBT
10	Capacitor	●CBB60 Plastic Shell Capacitor 〇 CBB65 Explosion-proof Capacitor 〇 450VL@220-240V Motor 〇 300VL@110-127VMotor
11	Motor Housing	Aluminum ADC12
12	Fan	●Plastic PP 〇 Nylon PA6
13	Fan Cover	Plastic PP
14	Plug Cord	● 3 Core Testing Cable 〇 Customized Cable Plug
15	Motor	〇Standard Copper Wire ● High Efficiency Motor 〇 Economical Motor 〇 3-Phase Motor 〇 Customized 60 HZ Motor
